CG-105 is a reflection-reducing coating material specially designed for glass substrates by Chenguang (Changzhou) New Material Technology Co. This product is applicable to different types and materials of glass, such as float glass, embossed glass, soda-lime glass, high alumina glass, etc. It has been commercially applied in the field of photovoltaic glass. CG-105 is based on the sol-gel technology of silica, using isopropanol as the dispersing medium, constructing a porous silica film layer on the surface of the glass, and realising the light transmittance by adjusting the refractive coefficient of the film layer; based on the independent pore structure, CG-105 has excellent durability, and is able to maintain its own optical performance under the harsh environmental conditions; based on Chenguang's patented Sol-StabTM technology, CG-105 can still maintain high stability without the use of strong acids. At the same time, after the special formula design, the coating area per unit quality is obviously increased, which significantly enhances the competitiveness of the product. The coating methods of this product include roller coating, dip coating, spraying, etc. It is also suitable for single-sided or double-sided coating. After the coating process is completed, the glass coated with CG-105 needs to be heat-treated to achieve its final performance, and it is recommended that the heat-treatment temperature be above 550°C. The thickness of the coating can be adjusted to change the reflective properties. The thickness of the coating can be adjusted to change the position of the lowest reflectance wavelength in the reflectance spectrum. Depending on the application, the minimum reflectance position may vary. Typical coating thicknesses range from 100-140nm. In addition, Chen Guang can provide a technical information package for the detailed application of this product under various process conditions.
