CG-1PBL8370-IR001 Pressed Automotive Ink
Chenguang New Material's new automotive glass coating business is able to provide a full set of automotive ink oil-based and water-based solutions with advantages of high acid resistance, stable performance, reliable process, green environmental protection and lower price. At present, the company's products have covered the needs of more than 90% of the car glass manufacturers, and fully realised domestic substitution. Product characteristics: used for pressing the front gear, sunroof CG-1PBL8370-IR001 is a lead-free and cadmium-free zinc borosilicate glass enamel system, mixed with heat-resistant pigments and pine oil alcohol binders, which can be used through the silk screen printing and thermal infrared drying process. This product is suitable for the pressing process of the front windshield of a car. It is suitable for flat and mold pressing processes.
PRODUCT SPECIFICATIONS
characterisation
Acid resistant for 72 hours, anti-stick, silver paste masking
Sintering temperature
580-640℃(No silver paste)
Appearance (visual)
Gloss/Semi-gloss/Matte
Color (visual)
Black
Silver paste hiding power
N/A
Optical density
≥3 (transmittance <0.1%)
Fineness
≤15μm
Scribe hardness
≥15N
Coefficient of thermal expansion
80-90·10-7/K(20-320℃)
Odor
Pine fragrance
Shelf life
12 months
