CG-1T8315HO-IR001 High Coverage Automotive Ink
Chenguang New Material's new automotive glass coating business is able to provide a full set of automotive ink oil-based and water-based solutions with advantages of high acid resistance, stable performance, reliable process, green environmental protection and lower price. At present, the company's products have covered the needs of more than 90% of the car glass manufacturers, and fully achieve domestic substitution. Product characteristics: for high coverage sunroof CG-1T8315HO-IR001 is a lead-free, cadmium-free, bismuth-based zinc borosilicate glass enamel system. It is mixed with heat-resistant pigments and resin binders such as pine oil, and can be used through the process of screen printing and thermal infrared drying. This product is suitable for tempered glass on the side and back of automobiles. It is suitable for flat and pressing processes.
PRODUCT SPECIFICATIONS
characterisation
Acid resistance 72 hours, OD>4
Sintering temperature
660-740℃(No silver paste)
Appearance (visual)
Gloss/Semi-gloss/Matte
Color (visual)
Black
Silver paste hiding power
△E≤1
Optical density OD
≥4 (transmittance <0.01%)
Fineness
≤15μm
Scribe hardness
≥15N
Coefficient of thermal expansion
80-90·10-7/K(20-320℃)
Odor
Pine scent
Shelf life
12 months
