CG-1T8315LB-IR001 Low Bismuth Content Tempered Automotive Ink
Chenguang New Material's new automotive glass coating business is able to provide a full set of automotive ink oil-based and water-based solutions with advantages of high acid resistance, stable performance, reliable process, green environmental protection and lower price. At present, the company's products have covered the needs of more than 90% of the car glass manufacturers, and fully achieve domestic substitution. Product characteristics: for low-cost needs of the rear gear, sunroof CG-1T8315LB-IR001 is a lead-free, cadmium-free, bismuth-based zinc borosilicate glass enamel system. It is mixed with heat-resistant pigments and pine oil binders and can be used through the silk screen printing and thermal infrared drying process. This product is suitable for tempered glass on the side and back of automobiles. It fits both flat and pressing processes.
PRODUCT SPECIFICATIONS
characterisation
Low cost, 90% of the normal cost of tempering ink.
Sintering temperature
660-740℃(No silver paste)
Appearance (visual)
Gloss/Semi-gloss/Matte
Color (visual)
Black
Silver paste hiding power
△E≤1
Optical density
≥3 (transmittance <0.1%)
Fineness
≤15μm
Scribe hardness
≥15N
Coefficient of thermal expansion
75-90·10-7/K(20-320℃)
Odor
Pine scent
Shelf life
12 months
